Description
Absolute best sonic performance at all price points
- Designed using state-of-the-art computer modeling software to vastly improve magnetic field and suspension linearity for consistent sonic performance at any SPL for best-in-class performance
- Pivoting woofer, midrange, and tweeter for improved frequency response in off-axis installations
Latest high-tech driver and tweeter material technology
- Improved low frequency performance
- Improved driver cone materials
- Low diffraction woofer, and midrange tweeter design
- Pivoting drivers for improved frequency response in off-axis installations
- Chambered midrange and tweeter design on all models
The chambered tweeter design does the following
- Lowers the resonance frequency of the tweeter
- Allows for a lower crossover frequency to the woofer
- Reduces the back pressure on the tweeter dome
- Reduces the distortion of the tweeter near the crossover frequency
| Tweeter | 1″ (25mm) ceramic dome, Ferrofluid-cooled, pivoting, in acoustic back chamber |
| Midrange | 4″ (102mm) Carbon fibre / Rohacell® laminated cone with a rubber surround, pivoting |
| Woofer | 8″ (203mm) Carbon fibre / Rohacell® laminated cone with a rubber surround, pivoting |
| Frequency Response | 30Hz – 20kHz ±3dB |
| Impedance | 6 ohms nominal – 4 ohms minimum |
| Power Handling | 5 watts minimum – 175 watts maximum |
| Sensitivity | 91dB SPL (2.83V/1 meter) |
| Adjustments | Tweeter Level Switch -3dB Flat +3dB |
| Grille | Perforated steel |
| Dimensions (Dia. x D) | 11 5/8 x 5 7/8 (295mm x 149mm) |
| Dimensions with Square Grille (W x H) |
11 3/4″ x 11 3/4″ (299mm x 299mm) |
| Cut-Out Dimensions (Dia.) | 10 1/8″ (257mm) |
| Shipping Weight | 22 lbs (10kg) pair |
