Description
Features and Benefits
Absolute best sonic performance at all price points
- Designed using state-of-the-art computer modeling software to vastly improve magnetic field and suspension linearity for consistent sonic performance at any SPL for best-in-class performance
Latest high-tech driver and tweeter material technology
- Improved low frequency performance
- Improved driver cone materials
- Low diffraction woofer & tweeter design
- Chambered tweeter design
The chambered tweeter design does the following
- Lowers the resonance frequency of the tweeter
- Allows for a lower crossover frequency to the woofer
- Reduces the back pressure on the tweeter dome
- Reduces the distortion of the tweeter near the crossover frequency
Easy to install
- Easy to access Roto-Lock® screws
- Removed metal hang tabs
- One-piece paintable grille with peel and stick scrim cloth for easier painting
- Two piece toggle feet allows installation with double dry wall and thicker ceiling and wall materials
Square adapter w/ grille can turn any round VP speaker into a square speaker (sold separately)
-
Allows easy alignment of the square grille with other ceiling features
| Tweeter | 1″ (25mm) cloth dome, Ferrofluid-cooled |
| Midrange | – |
| Woofer | 8″ (203mm) polypropylene cone with a rubber surround |
| Frequency Response | 42Hz – 20kHz ±3dB |
| Impedance | 8 ohms nominal; 6 ohms minimum |
| Power Handling | 5 watts minimum; 125 watts maximum |
| Sensitivity | 90dB SPL (2.83V/1 meter) |
| Grille | Perforated steel |
| Adjustments | – |
| Dimensions (Dia. x D) | 11 5/8″ x 3 3/4″ (295mm x 95mm) |
| Dimensions (W x H) | 11 3/4″ x 11 3/4″ (299mm x 299mm) |
| Cut-Out Dimensions (W x H) | 10 1/8″ (257mm) |
| Shipping Weight | 12.5 lbs (5.67kg) pair |
