Description
Absolute best sonic performance at all price points
- Designed using state-of-the-art computer modeling software to vastly improve magnetic field and suspension linearity for consistent sonic performance at any SPL for best-in-class performance
Latest high-tech driver and tweeter material technology
- Improved low frequency performance
- Improved driver cone materials
- Low diffraction woofer and tweeter design
- Pivoting tweeter for improved frequency response in off-axis installations
- Chambered tweeter design on all models
The chambered tweeter design does the following
- Lowers the resonance frequency of the tweeter
- Allows for a lower crossover frequency to the woofer
- Reduces the back pressure on the tweeter dome
- Reduces the distortion of the tweeter near the crossover frequency
Easier to install
- Easier to access Roto-Lock® screws
- Removed metal hang tabs
- One-piece paintable grille with peel and stick scrim cloth for easier painting
- Two piece toggle feet allows installation with double dry wall and thicker ceiling and wall materials
| Tweeter | 1″ (25mm) cloth dome, Ferrofluid-cooled, pivoting, in acoustic back chamber |
| Woofer | 6 1/2″ (165mm) textured polypropylene cone with a rubber surround |
| Frequency Response | 45Hz – 20kHz ±3dB |
| Impedance | 8 ohms nominal – 6 ohms minimum |
| Power Handling | 5 watts minimum – 125 watts maximum |
| Sensitivity | 89dB SPL (2.83V/1 meter) |
| Grille | Perforated steel |
| Dimensions (Dia. x D) | 9 3/4″ x 3 5/32″ (248mm x 80mm) |
| Dimensions with Square Grille (W x H) |
9 7/8″ x 9 7/8″ (251mm x 251mm) |
| Cut-Out Dimensions (Dia.) | 8 1/4″ (210mm) |
| Shipping Weight | 9 lbs (4.1kg) pair |
