Description
Features and Benefits
Absolute best sonic performance at all price points
- Designed using state-of-the-art computer modeling software to vastly improve magnetic field and suspension linearity for consistent sonic performance at any SPL for best-in-class performance
Latest high-tech driver and tweeter material technology
- Improved low frequency performance
- Improved driver cone materials
- Low diffraction woofer & tweeter design
- Chambered tweeter design
The chambered tweeter design does the following
- Lowers the resonance frequency of the tweeter
- Allows for a lower crossover frequency to the woofer
- Reduces the back pressure on the tweeter dome
- Reduces the distortion of the tweeter near the crossover frequency
Easy to install
- Easy to access Roto-Lock® screws
- Removed metal hang tabs
- One-piece paintable grille with peel and stick scrim cloth for easier painting
- Two piece toggle feet allows installation with double dry wall and thicker ceiling and wall materials
Square adapter w/ grille can turn any round VP speaker into a square speaker (sold separately)
-
Allows easy alignment of the square grille with other ceiling features
| Tweeter | 1″ (25mm) cloth dome, Ferrofluid-cooled |
| Midrange | – |
| Woofer | 5 1/2″ (165mm) polypropylene cone with a rubber surround |
| Frequency Response | 48Hz – 20kHz ±3dB |
| Impedance | 8 ohms nominal; 6 ohms minimum |
| Power Handling | 5 watts minimum; 100 watts maximum |
| Sensitivity | 89dB SPL (2.83V/1 meter) |
| Grille | Perforated steel |
| Adjustments | – |
| Dimensions (Dia. x Depth) | 9 3/4″ x 3 3/4″ (248mm x 95mm) |
| Cut-Out Dimensions (Dia) | 8 1/4″ (210mm) |
| With Square Adapter and Grille (WxH) | 9 7/8” (251mm) x 9 7/8” (251mm) |
| Shipping Weight | 9 lbs (4.1kg) pair |
